CAD Drafting
Professional CAD drafting services
Accurate, standards-compliant 2D drafting across all disciplines. From architectural floor plans to MEP layouts, we deliver precise documentation that meets your project requirements.
Precision Drafting for Every Discipline
Quality 2D drawings remain essential for construction documentation, permit submissions, and project communication. Our experienced drafters produce accurate, well-organized CAD drawings that meet industry standards and your specific project requirements.
Whether you need new drawings, redline revisions, or conversion of legacy documents, we deliver reliable CAD services with quick turnaround.
What We Offer
CAD Drafting Disciplines
Professional drafting across architectural, structural, MEP, and civil disciplines.
Architectural CAD
Precise 2D architectural drawings including floor plans, elevations, sections, and details.
Structural CAD
Detailed structural drafting for steel, concrete, and timber construction.
MEP CAD
Comprehensive mechanical, electrical, and plumbing drafting for building systems.
Civil CAD
Site development and civil engineering drawings for infrastructure projects.
CAD Conversion
Digitization and conversion of legacy drawings, sketches, and PDFs to CAD format.
How We Work
How a drafting package is produced
Drawings generated to your standard and checked back against their source before issue.
Input review
Approved models, IFC drawings, specifications and the fabricator's standards are reviewed together before anything is drawn, and we flag conflicts between them in writing.
Coordination status check
We confirm the model area is actually coordinated and signed off. Producing fabrication drawings from an uncoordinated model is the most expensive mistake in this service.
Drawing production
Trade-specific sheets generated from the coordinated model to your title block and layer standard, at the scales your fabricator works to.
Dimensioning and detailing
Fully dimensioned, tagged and annotated to fabrication standards, so the shop is not left making assumptions in the field.
Model-to-sheet verification
Every sheet is checked back against the model it came from, so a late model change cannot survive as a stale drawing.
Two-pass QA
A lead detailer review, then an independent check against the specification and applicable standards, both recorded.
Submittal package
Sheets assembled into the submittal structure you need, in the formats your reviewer expects.
Revision turnaround
Review comments are logged, classified as correction or scope change, actioned and re-checked through the same gates.
Our Benefits
What you actually get
Drawings produced to your standard and verified against their source.
Reviewed by a registered architect
Aercon is architect-led — a registered architect oversees delivery, so your model is questioned on design and constructability, not only geometry. Sealing and professional responsibility stay with your professionals of record.
We check the model is coordinated first
Drawings are only produced from a signed-off area. Fabrication drawings from an uncoordinated model is the most expensive mistake in this service, and we refuse it rather than bill for it.
No field assumptions
Sheets are fully dimensioned, tagged and annotated to fabrication standards, so the shop is not guessing and you are not answering avoidable RFIs.
Checked back against the model
Every sheet is verified against the model revision it came from, so a late model change cannot survive as a stale drawing in the set.
Your template, not ours
We work inside your template, shared parameters, naming convention and BIM Execution Plan. Nothing comes back needing to be re-mapped to your standard.
Your drawings stay yours
NDA before we receive anything, access limited to the named project team, and we never reuse a client's models, families or drawings for anyone else.
Our Work
CAD Documentation Projects
See examples of our drafting work across various sectors.
Sectors
Industries We Serve
Delivering BIM excellence across diverse sectors with tailored solutions.
FAQ
Frequently Asked Questions
Need professional CAD drafting?
Get accurate drawings from our experienced team.
